W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags

W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags

  • W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags
  • W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags
  • W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags
  • W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags
W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags
제품 상세 정보:
원래 장소: 광저우 중국
브랜드 이름: GUOMAT
인증: ISO/TS16949, ISO9001
모델 번호: 2B6940
결제 및 배송 조건:
최소 주문 수량: 5PCS
가격: USD59.9-69.9/PC
포장 세부 사항: 강력한 카톤 박스 또는 고객 요구 사항
배달 시간: 3-7 영업일
지불 조건: L/C, T/T, Western Union 또는 기타
공급 능력: 1000pcs/주
접촉
상세 제품 설명
압력 능력: 0.2-0.8 M PA 운송 패키지: 상자
재료: 고무와 강철 보증: 12개월
컨볼 루션: 2 Firestone: W01-358-6940
굿 이어: 2B9-230 뇌졸중: 81mm-274mm
강조하다:

Firestone Suspension Air Spring replacement

,

Goodyear Airide air bags

,

2B9-230 air spring

W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags
W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags
Manufacturer Cross OEM Reference
Firetsone Part Number: W01-358-6940 / W01 358 6940 / W013586940
Contitech Part Number: FD200-19 450 / FD 200-19 450
Contitech Part Number: 161296
Goodyear Part Number: 2B9-230 / 2B 9-230 / 2B9 230
Goodyear Bellows Number: 578923202 / 578 92 3 202 / 578-92-3-202
Triangle Part Number: 6325 / 4450
Histeer: 10305
Taurus: 6325
Triangle: AS-4450
TRP: AS69400
Loadguard: SC3762 / SC 3762
Loadguard: SC2035 / SC 2035
Fabio: 2DC-220-35C
Technical Data
The cover plate diameter: 160mm
Max.height: 274mm
Min.height: 81mm
The rubber bellows max.outer diameter: 251mm
Center distance between bottom bolts: 89mm
Working Principle of Air Springs in Paper Filter Press
Component Role Working Process Core Action
As a Pressure Source Compressed air is fed into the air springs mounted on a fixed roll core. Inflate & Expand to apply uniform outward pressure against the rotating roll shell.
As a Pressure Regulator The control system independently adjusts the air pressure in springs across multiple zones along the roll length. Zone Pressure Control to precisely manage the load at different points across the roll face.
As a Deflection Compensator Automatically increases the pressure in the center zone springs to counteract the roll's natural bending under load. Compensate Deflection to ensure a uniform pressure profile across the entire sheet for even dewatering.
As a Shock Absorber When encountering sheet splices or thickness variations, the air springs compress to absorb the impact. Cushion & Dampen vibrations, protecting the equipment and ensuring stable operation.
The drawing and data of GUOMAT 2B6940 air spring:
W01-358-6940 Firestone Suspension Air Spring 2B9-230 Goodyear Airide Replacement Air Bags 0
